Trane MOT13501 Condenser Fan Motor 1/6 HP 208-230V

Product Description

The Trane MOT13501 is a condenser fan motor suitable for air conditioning applications. It functions on a voltage range of two hundred eight to two hundred thirty volts and operates at a frequency of sixty hertz. With a horsepower of one-sixth, this motor completes rotations at a speed of 1075 RPM. This unit features a forty-eight frame size and a shaft measuring half by six inches. It is designed with a totally enclosed air-over enclosure and can rotate in both clockwise and counterclockwise directions. The installation can be done using band or stud mounting techniques.

• Power: 1/6 HP
• Voltage: 208-230V
• Rotation: Clockwise and Counterclockwise

Product Highlights

This motor is ideal for HVAC systems and offers reliable operation in various conditions.

Product Information

Standard Information

• Enclosure Type: Totally Enclosed Air-Over
• Frame Size: 48

Technical Specifications

• Frequency: 60 Hz
• Load Current: 0.9 A
• Motor Type: AC, Condenser Fan
• Mounting Type: Band/Stud
• Number of Speeds: 1
• Phase: 1
• RPM: 1075
• Voltage: 208-230V
