Trane M4MHW1712A1N0A 17 SEER Mini-Split 12MBH HP IDU 208-230/60/1

Product Description

The Trane M4MHW1712A1N0A is a ductless mini-split air handler with a SEER rating of 17. It is designed for wall mounting and operates efficiently for residential spaces. The product comes fully charged and supports piping extensions of up to twenty-five feet, making it versatile for various installations. The unit can handle outdoor temperatures up to one hundred fifteen degrees Fahrenheit.

• Accommodates piping extensions of up to twenty-five feet
• Handles outdoor conditions up to one hundred fifteen degrees Fahrenheit
• Constructed from galvanized steel with a weather-resistant finish

Product Highlights

This mini-split air handler is ideal for spaces between five hundred to six hundred square feet. Its installation is straightforward, and it provides reliable climate control.

Product Information

Standard Information

• Model: M4MHW1712A1N
• UPC: 601954744066

Technical Specifications

• Product Height: 11.37 inches
• Product Length: 33.26 inches
• Product Width: 8.23 inches
• Blower Motor: Variable Speed
• Cooling Capacity: 1 Ton
• Electrical Phase: 1-Phase
• Line Set Connection Type: Flared
• Liquid Line Size: 1/4 inch
• Max Overcurrent Protection: 15 amps
• Refrigerant: R-410a
• Suction Line Size: 3/8 inch
• System Application Type: Ductless Split Systems
• Voltage: 208-230
• Warranty: 5 Year Parts
