TRANE J4GXCB004AC6HUA Evaporator Coil

Product Description

The TRANE J4GXCB004AC6HUA is an evaporator coil specifically designed for central air conditioning systems. It features an all-aluminum coil which optimizes heat transfer efficiency. The coil is encased in a durable, foil-faced insulation material, enhancing energy efficiency and performance. This unit supports both upflow and downflow configurations, making it versatile for various installation requirements.

• All-aluminum coil for efficient heat transfer
• Insulated with foil-faced material
• Compatible with upflow and downflow installations

Product Highlights

This evaporator coil integrates seamlessly with central air systems to effectively transfer heated or cooled air where needed.

Product Information

Standard Information

• Product Category: Evaporator Coil
• Refrigerant Type: R-410A

Technical Specifications

• Type: Evaporator Coil
• Product Line: J4GXC
• Casing: Cased
• Style: A Coil
• Configuration: Upflow/Downflow
• Capacity: 1.5 - 3.0 Tons
• Suction Connection Size: 3/4 Inch
• Liquid Connection Size: 3/8 Inch
• Cabinet Width: 17.5 Inches
• Product Height: 20 Inches
• Product Width: 17.5 Inches
• Product Depth: 21 Inches
• Product Weight: 44 Pounds
• ETL Listed: Yes
• AHRI Certified: Yes
• Warranty: 5 Years
