Trane CNT04021 Low-Pressure Control 250 VAC 6 mm ODM Solder

Product Description

Trane CNT04021 Low-Pressure Control operates at 250 VAC and features a connection size of six millimeters. This control is designed for low-pressure applications with an open pressure of twenty-five psi and a close pressure of forty-five psi. It uses a one normally open (1NO) single pole single throw (SPST) switch and connects via ODM solder. This product is suitable for temperatures ranging from negative thirty to eighty-five degrees Celsius and comes in an IP65 waterproof enclosure.

• 250 VAC voltage rating
• Temperature range from -30 to 85 degrees Celsius
• Compatible with 4A6H6048A1000AA Air Conditioner

Product Highlights

Reliable low-pressure control with a robust waterproof design. Ideal for HVAC systems.

Product Information

Standard Information

• Voltage Rating: 250 VAC
• Temperature Rating: -30 to 85 deg C

Technical Specifications

• Open Pressure: 25 psi
• Close Pressure: 45 psi
• Switch Type: 1NO, SPST
• Connection Size: 6 mm
• Connection Type: ODM Solder
• Enclosure Type: IP65, Waterproof
• Suitable For Use With: 4A6H6048A1000AA Air Conditioner
• Additional Information: 18 AWG Wire Gauge
