Trane BKR02360 breaker 80 A H-frame

Product Description

The Trane BKR02360 Breaker is an 80 A H-frame circuit breaker. It is a thermal magnetic type designed to safeguard electrical circuits and equipment by interrupting overloads. This 3-pole breaker supports 3-phase systems with 600V AC and 250V DC voltage ratings, and a frequency of 50/60 Hz. It features line and load side lug terminal connections.

• Safeguards electrical circuits and equipment
• Interrupts overloads to protect the system and maintain reliable operation
• UL, CSA, CE, IEC Standards Compliant

Product Highlights

Thermal magnetic circuit breaker for circuit protection and overload interruption, compliant with UL, CSA, CE, and IEC standards.

Product Information

Standard Information

• Brand: TRANE
• Manufacturer Part Number: BKR02360

Technical Specifications

• Manufacturer: Trane
• Manufacturer Part Number: BKR02360
• Product Type: Circuit Breaker
• Current Rating: 80A
• Number of Poles: 3
• AC Voltage: 600V
• DC Voltage: 250V
• Frame Type: H-Frame
• Mounting Type: Unit
• Breaker Type: Thermal Magnetic
• Standards: UL, CSA, CE, IEC
• Temperature Rating: 104 Deg. F
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 65 kA at 480V AC, 25 kA at 600V AC, 100 kA at 240V AC
• Number of Phases: 3
• Terminal Connection Type: Line and Load Side Lug
