Trane A952V060BU4SAC Two Stage Condensing Gas Furnace 60000 Btu/h Upflow Horizontal

Product Description

The Trane A952V060BU4SAC is a two-stage, condensing gas-fired furnace rated at 60,000 BTU/h input capacity. It is designed for upflow installation and is field-convertible to horizontal right or horizontal left orientation, giving installers flexibility in tight or unconventional spaces. The unit falls within the RunTru product line and features a two-stage gas valve that modulates heat output to match load conditions, reducing short cycling and improving distribution. Licensed HVAC technicians handling residential or light-commercial new construction and replacement work are the primary installers for this unit. The B-size cabinet footprint suits standard platform or closet installations.

This furnace is suited for residential split-system applications where a condensing-efficiency gas furnace is required. The upflow configuration makes it compatible with above-plenum duct systems, while the convertible horizontal orientation allows attic or crawlspace sideflow installs. According to submittal documentation, the A952V060BU4SAC designation supersedes the earlier variant A952V060BU4SAB, and Trane Supply indicates it is itself superseded by A952V060BU4SBA. Contractors managing inventory transitions should confirm the current active replacement before ordering.

Key Features

• Two-stage gas valve operation reduces short cycling and improves temperature consistency
• 60,000 BTU/h input rating suits mid-size residential heating loads
• Upflow configuration with field conversion to horizontal right or horizontal left
• Condensing design extracts additional heat from flue gases for higher efficiency
• B-size cabinet fits standard residential platform and closet applications
• Supersedes A952V060BU4SAB; itself superseded by A952V060BU4SBA per Trane Supply records

Compatibility

The A952V060BU4SAC is documented as superseding part number A952V060BU4SAB and is in turn superseded by A952V060BU4SBA according to Trane Supply product records. Verify current replacement chain with Trane Supply before specifying on new installations.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with the manufacturer installation manual, local mechanical codes, and IFGC requirements. Shut off gas supply and disconnect electrical power at the disconnect or breaker before beginning any service or replacement work. The convertible horizontal orientation requires proper condensate drainage planning when the unit is installed on its side. Always verify venting configuration and flue pipe sizing meets local code for condensing appliances before startup.

Technical Specifications

• Input Capacity: 60,000 BTU/h
• Stages: Two-stage
• Furnace Type: Condensing Gas-Fired
• Airflow Configuration: Upflow, convertible to Horizontal Left or Horizontal Right
• Cabinet Size: B
• Supersedes: A952V060BU4SAB
• Superseded By: A952V060BU4SBA

Standard Information

• Brand: Trane
• Manufacturer Part Number: A952V060BU4SAC
