Trane A5AC5060A1000 Split System Air Conditioner 60000 Btu/h 5 Ton R-454B 208-230V Single Stage

Product Description

The Trane A5AC5060A1000 is a single-stage split system air conditioning condensing unit rated at 60,000 BTU/h (5 tons) of cooling capacity. It operates on R-454B refrigerant and uses a 24-volt control circuit with a power supply of 208-230/1/60 (single-phase, 60 Hz). The coil assembly is all-aluminum construction, which reduces the risk of formicary corrosion common with copper-aluminum combinations. This unit is marketed under the RunTru by Trane and Ameristar by American Standard brands. Licensed HVAC technicians install and commission this unit as the outdoor half of a matched split cooling system.

The A5AC5060A1000 is designed for residential split system cooling applications. It is factory charged with refrigerant for the condensing unit itself, ten feet of tested connecting line, and the smallest rated indoor evaporative coil match. When paired with a compatible air handler, verified matched system combinations include the A5AHV006A1D30A variable speed air handler and the A5AHC007A1D30A convertible air handler, with paired system SEER2 ratings documented at 15.0 to 15.2 depending on the indoor unit selected.

Key Features

• 60,000 BTU/h (5-ton) single-stage cooling output
• R-454B refrigerant — lower global warming potential alternative to R-410A
• All-aluminum coil construction for corrosion resistance
• 24-volt system control interface for standard thermostat compatibility
• 208-230/1/60 power configuration suits standard residential electrical service
• Factory refrigerant charge sized for condensing unit plus ten feet of line set and smallest rated indoor coil
• A-weighted sound power level of 71 dB(A), rated per AHRI Standard 270-2008

Compatibility

Documented matched system pairings include the A5AHV006A1D30A variable speed air handler (15.0 SEER2) and the A5AHC007A1D30A convertible air handler (15.2 SEER2). Confirm matched indoor unit selections using current AHRI certified ratings before installation. Additional compatible indoor units may exist; consult Trane product data for the full matchup table under model series A5AC5060A.

Installation Notes

Installation must be performed by a licensed HVAC technician holding the appropriate EPA Section 608 certification for handling refrigerants. Disconnect and lock out all electrical power to the system before making any electrical or refrigerant connections. Line set length and diameter must conform to manufacturer specifications; deviating from the factory charge assumption of ten feet requires a field refrigerant charge adjustment. Follow all local mechanical codes and the current edition of applicable standards when setting, brazing, and pressure-testing the refrigerant circuit.

Technical Specifications

• Cooling Capacity: 60,000 BTU/h (5 tons)
• Refrigerant Type: R-454B
• Voltage: 208-230 volts, single-phase, 60 Hz
• System Control Voltage: 24 volts
• Coil Material: All aluminum
• Sound Power Level: 71 dB(A) (AHRI Standard 270-2008)
• Unit Height (A dimension): 44.625 inches
• Unit Width (B dimension): 34.25 inches
• Base Dimension C: 0.875 inches
• Base Dimension D: 1.75 inches
• System Type: Split system, outdoor condensing unit
• Application: Residential split system cooling

Standard Information

• Brand: Trane
• Manufacturer Part Number: A5AC5060A1000
