Trane A4AH4E42B1C30A RunTru Air Handler 3.5 Ton 23.5 inches Cabinet

Product Description

The TRANE A4AH4E42B1C30A RunTru Air Handler ensures consistent air circulation. With an air leak rate of 2% or less, it efficiently handles spaces from 1750 to 2100 square feet. The R-4.2 insulating value is ideal for reducing heat loss. It uses fused 24V power and low voltage pigtail connections, with a draw through design for uniform air velocity.

• Air leak rate of 2% or less
• Handles spaces ranging from 1750 to 2100 square feet
• R-4.2 insulating value

Product Highlights

This 3.5 Ton TRANE RunTru air handler features a corrosion-resistant aluminum coil, ECM motor, and can be installed in upflow, downflow, and left/right horizontal configurations.

Product Information

Standard Information

• Brand: TRANE
• Manufacturer Part Number: A4AH4E42B1C30A

Technical Specifications

• Model: A4AH4E42B1C30A
• UPC: 647535674445
• Product Height (in): 51.4
• Configuration: Floor Mounted
• Product Length (in): 21.13
• Air Flow Direction: Downflow, Horizontal, Upflow
• Product Width (in): 23.5
• Blower Motor: High Efficiency
• Cooling Capacity: 3.5 Ton
• Electrical Phase: 1-Phase
• Heat Strip Compatibility: Up to 20 kW
• Line Set Connection Type: Sweat
• Liquid Line Size: 3/8 inch
• Max Overcurrent Protection: 15 amps
• Refrigerant: R-410a
• Suction Line Size: 7/8 inch
• System Application Type: Central Split Systems
• Voltage: 240
