Trane ECC240A3E0A1HAH Air Handler 20 Ton 208/230V 3-phase

Product Description

The TRANE ECC240A3E0A1HAH is a commercial-duty ducted split system air handler engineered for R-410A refrigerant in dedicated cooling applications. Rated at 20 tons of cooling capacity, this unit operates on 208/230 volts, 3-phase, 60 Hz power, making it suited for larger commercial or light-industrial installations. The ECC240A3E0A1HAH is designed to work within a split system configuration, handling conditioned air distribution through a ducted network. Licensed HVAC technicians and mechanical contractors handle installation, sizing, and commissioning of units at this capacity level.

This air handler is intended for commercial cooling applications where a high-capacity ducted split system is required. At 20 tons, it serves larger spaces such as commercial buildings, retail facilities, or light-industrial spaces. The unit operates on 3-phase power, which is standard for commercial mechanical rooms and rooftop equipment installations. It is designed for use with R-410A refrigerant as part of a matched split system.

Key Features

• 20-ton cooling capacity for high-demand commercial applications
• R-410A refrigerant compatible — meets current refrigerant standards
• 208/230V, 3-phase, 60 Hz electrical configuration for commercial power infrastructure
• Ducted split system design for centralized air distribution
• Dedicated cooling unit type for purpose-built cooling systems

Compatibility

Designed as an OEM-matched ducted split system air handler for commercial R-410A cooling applications operating on 208/230V 3-phase power. Verify matched outdoor condensing unit compatibility with a Trane equipment schedule or submittal before installation.

Installation Notes

Installation of a 20-ton commercial air handler must be performed by a licensed HVAC contractor and is subject to local mechanical codes and NEC requirements for 3-phase electrical connections. Disconnect and lock out all electrical power before servicing or making refrigerant connections. R-410A systems require EPA Section 608 certified technicians for refrigerant handling. Confirm duct system static pressure and airflow design before startup.

Technical Specifications

• Unit Type: Cooling
• Cooling Capacity: 20 tons
• Voltage: 208/230V
• Phase: 3-phase
• Frequency: 60 Hz
• Refrigerant: R-410A
• System Type: Ducted Split System

Standard Information

• Brand: TRANE
• Manufacturer Part Number: ECC240A3E0A1HAH
