TOSHIBA VFS15-2110PM-W1 Adjustable Speed Drive

Product Description

The TOSHIBA VFS15-2110PM-W1 is an adjustable speed drive suitable for various applications. This drive controls both variable and constant torque, making it versatile for different motor types. It is compatible with permanent magnet motors, allowing for flexible installations.

• Supports permanent magnet (PM) motors
• Features adjustable PWM carrier frequency from two to sixteen kHz
• Includes an integral four-digit and seven-segment LED keypad for easy programming and diagnostics

Product Highlights

This drive is designed for high performance and can operate in extreme conditions, maintaining functionality in temperatures up to fifty degrees Celsius.

Product Information

Standard Information

• Manufacturer: Toshiba
• Series: ASD S Series

Technical Specifications

• Motor Capacity: 11 kW
• Horsepower: 15 HP
• Capacity: 20.6 kVA
• Input Voltage: 3-phase 240V
• Output Voltage: 3-phase 200V to 240V
• Output Frequency: 0.1 to 500 Hz
• Rated Output Current: 54.0 A
• Overload Current Rating: 150% for 60 seconds
• Control Method: Sinusoidal Pulse Width Modulation, Flux-Field Current Vector Control
• V/Hz Control: V/f Constant, Variable Torque, Automatic Torque Boost, Vector Control, PM Motor Control
• Frequency Setting: Various methods including rotary encoder and analog inputs
• Speed Regulation: Up to 0.1%, 60:1 Speed Range
• Digital Input: Programmable with six discrete input terminals
• Analog Output: One Programmable 4 to 20 mA or 0 to 10 VDC
• Communication Ports: RS485 Port for MODBUS RTU Protocol
• Display: Integral four-digit and seven-segment LED keypad
• IP Rating: IP20
• Cooling: Self-Cooling/ Forced Air-Cooled
• Ambient Temperature: -10 to +60 C
• Weight: 8.8 kg
• Standards: UL Listed, CSA, CE
