TOSHIBA 0404FAGR41A-P Electric Motor 40 HP

Product Description

The TOSHIBA 0404FAGR41A-P is a 3-phase electric motor with a power rating of 40 horsepower and a speed of 1800 RPM. This motor operates on 230/460 volts and is built for efficiency and reliability. The design features a Totally Enclosed Air Over (TEAO) enclosure that protects against dust and moisture, making it suitable for cooling tower applications and other industrial uses. It meets NEMA MG1 Part 31 standards, ensuring high performance and durability.

• Horsepower: 40 HP
• Speed: 1800 RPM
• Enclosure Type: TEAO

Product Highlights

This electric motor is designed for demanding environments with a high degree of efficiency.

Product Information

Standard Information

• Manufacturer: Toshiba Motors
• Motor Voltage Phases: 3 Phase

Technical Specifications

• Horsepower: 40 HP
• Motor Frequency: 60 Hz
• Input Voltage: 230/460 Volt
• Motor RPM's: 1800 RPM
• Motor Amperage (Full Load): 96 Amp
• Enclosure: TEAO
• Frame Type: 324T
• Locked Rotor Torque: 180
• Full Load Torque (lb-ft): 118
• Weight: 669 lbs
