TOSHIBA 0112SDMW7FS-PL Electric Motor Power 11 kW

Product Description

The TOSHIBA 0112SDMW7FS-PL is an electric motor built for efficiency and reliability. This three-phase motor conforms to IEC 60034 standards and is suitable for severe duty applications, making it ideal for demanding settings. It operates at both fifty and sixty hertz, with a power output of eleven kilowatts, and a voltage rating of four hundred volts. The motor features a Totally Enclosed Fan Cooled (TEFC) enclosure, ensuring protection in various environments.

• Operates on a three-phase system.
• Dual frequency design for versatile applications.
• Footed mounting for easy installation.

Product Highlights

Product Information

Standard Information

• Brand: TOSHIBA
• MPN: 0112SDMW7FS-PL

Technical Specifications

• Phase: 3 ph
• Motor Enclosure Type: TEFC
• Frame Size: 160M
• Rated Speed: 3000 rpm
• Power Rating: 11 kW
• Horsepower: 15 HP
• Input Voltage: 400 V
• Full Load Amperage: 20 A
• Efficiency: 91.2%
• Power Factor: 86.1%
• Service Factor: 1.15
• Insulation Class: Class F
• Temperature Rating: 40 deg C
• Rotation Type: CCW/CW
• Weight: 205 lbs
