TOSHIBA 0054FAGR41A-P Electric Motor 5 HP

Product Description

The TOSHIBA 0054FAGR41A-P is a three-phase electric motor tailored for cooling tower applications. It is designed for use in humid environments and features a Totally Enclosed Air Over (TEAO) enclosure. This motor is ideal for continuous duty and can be mounted in both horizontal and vertical orientations.

• Supports adjustable speed drives
• Designed for continuous operation in wet conditions
• Insulation system meets NEMA MG1 Part 31

Product Highlights

This electric motor is suitable for HVAC systems, chiller applications, and blower motors.

Product Information

Standard Information

• Manufacturer: Toshiba Motors
• Motor Voltage Phases: 3 Phase

Technical Specifications

• Motor Horsepower: 5 HP
• Motor Frame Model: 184T
• Motor Frequency: 60 Hz
• Motor Voltage: 230/460 VAC
• Motor RPM: 1800 RPM
• Service Factor: 1.15
• Temperature Rating: -13 to 104 deg F
• Insulation Class: Class F
• Material: Cast Iron
• Weight: 137 lbs
• Dimensions: 13-1/2 in L x 9-1/2 in W x 9-1/2 in H
