TOSHIBA 0022SDSR42H-P Electric Motor 2 HP

Product Description

The TOSHIBA 0022SDSR42H-P is a reliable three-phase electric motor designed for various applications, including general and severe duty work. It features a totally enclosed fan-cooled (TEFC) enclosure, ensuring efficient performance and protection against environmental factors.

• 2 HP power output
• Operates at 3600 RPM
• Voltage rating of 230/460 volts

Product Highlights

This motor is equipped with oversized bearings and Class F insulation for enhanced durability and reliability.

Product Information

Standard Information

• Brand: TOSHIBA
• MPN: 0022SDSR42H-P

Technical Specifications

• Motor Enclosure Type: TEFC
• Voltage Phases: 3 Phase
• Horsepower: 2 HP
• Frequency: 60 Hz
• Voltage: 230/460 V
• Speed: 3600 RPM
• Frame Size: 56C
• Full Load Amperage: 5.2/2.6 A
• Service Factor: 1.15
• Weight: 53 lbs
• Efficiency: 85.5 %
• Mounting Type: C-Face Footed
• Insulation Class: Class F
• Material: Cast Iron
• Number of Poles: 2
• Number of Speeds: 1
• Rotation Type: CCW/CW
• Temperature Rating: 40 deg C
• Duty Type: Severe
• Dimensions: 13.58 in L x 7.95 in H
• Bolt Circle Diameter: 5-7/8 in
