Toro 306-00 135 Degree Arc Plate 300 Series

Product Description

The TORO 306-00 is a 135-degree arc plate designed for use with Toro 300 Series irrigation rotors. Arc plates set the fixed spray pattern angle on rotor-style sprinkler heads, controlling the sweep range of the rotating stream. This plate locks the rotor to a 135-degree arc, making it suitable for corner and irregular-shaped turf zones where a partial-circle pattern is required. Installation is performed by irrigation technicians and landscaping professionals during head setup or arc-pattern adjustment in the field.

The 306-00 arc plate is used in residential and light commercial irrigation systems equipped with Toro 300 Series rotors. It is particularly useful in zones where site geometry does not allow for full-circle or standard 180-degree coverage, such as narrow side yards, angled beds, or corner lawn areas. The arc plate is typically swapped in or out during system commissioning or seasonal reconfiguration without removing the rotor body from the ground.

Key Features

• Fixed 135-degree arc setting for precise partial-circle coverage
• Designed specifically for Toro 300 Series rotor heads
• Allows field adjustment of spray pattern without full head replacement
• Compact plate format simplifies on-site arc changes

Compatibility

Designed as an OEM-style arc plate replacement for Toro 300 Series irrigation rotors.

Installation Notes

Arc plate installation and replacement is performed by qualified irrigation technicians. Shut off system water supply and depressurize the zone before servicing the rotor head. Use manufacturer-recommended tools to remove the rotor cap and access the arc plate mechanism. Follow local irrigation and plumbing codes when making any adjustments to installed irrigation systems.

Technical Specifications

• Arc Angle: 135 degrees
• Series Compatibility: 300 Series
• Order Increment: 1
• UPC: 090258009320

Standard Information

• Brand: TORO
• Manufacturer Part Number: 306-00
