Topaz LPLTA-9W-CTSW-H UL Type A PLT 9W (Horizontal) LPLTA9WCTSWH

Product Description

Topaz LPLTA-9W-CTSW-H is a 9W UL Type A PLT retrofit lamp that is ballast compatible and offers CCT selectable outputs at 3500K, 4000K, and 5000K. Designed for horizontal mounting, the lamp replaces 13W, 18W, and 26W 2- and 4-pin CFLs, is suitable for enclosed fixtures and damp locations, and can dim with compatible 0-10V dimming ballasts. Typical lumen output ranges around 1000–1050 lm with a rated life up to 50,000 hours.

• 9W UL Type A PLT retrofit lamp; ballast compatible
• CCT selectable: 3500K, 4000K, 5000K
• Replaces 13W/18W/26W 2- and 4-pin CFLs; suitable for enclosed fixtures and damp locations; compatible with 0-10V dimming ballasts

Product Highlights

Horizontal ballast-compatible PLT retrofit with selectable CCT and approximately 1000–1050 lumens; rated life up to 50,000 hours.

Product Information

Standard Information

• Brand: TOPAZ
• Manufacturer Part Number: LPLTA-9W-CTSW-H

Technical Specifications

• Brand: Topaz
• Manufacturer Part Number: LPLTA-9W-CTSW-H
• Alternate Part Numbers: LPLTA9WCTSWH, TPZLPLTA9WCTSWH
• SKU: LPLTA-9W-CTSW-H-TZ
• UPC: 751338040595
• Wattage: 9W
• Lamp Type: UL Type A PLT retrofit
• Base Type: G24Q
• Ballast Compatibility: Ballast compatible (UL Type A)
• CCT: CCT selectable: 3500K / 4000K / 5000K
• Orientation: Horizontal
• Replaces: 13W, 18W, 26W 2- and 4-pin CFL lamps
• Dimmable: Compatible with 0-10V dimming ballasts
• Lumens: Approx. 1000–1050 lm
• Average Life: 50,000 hrs
• CRI: 83
• Beam Angle: 120°
• Power Factor: 0.9
• Operating Temperature: Min -20°C (-4°F); Max 45°C (113°F)
• Certifications: DLC 5.1, UL Listed, RoHS
• Material: Polycarbonate housing with aluminum heat sink and frosted lens
• Rotatable Angle: Up to 300°
• Rated Location: Damp locations; suitable for enclosed fixtures
• Dimensions: 1.69 in (L) x 1.30 in (W) x 5.98 in (H)
• Weight: 0.22 lb
• UPC/GTIN: 751338040595
