Topaz 653SIRT 1in STL CMPRN EMT CONN (1 Inch)

Product Description

The Topaz 653SIRT is a 1-inch steel compression EMT connector with an insulated throat. These EMT connectors feature a compression type assembly and provide a raintight and concrete tight connection. It is used to securely bond EMT thin wall conduits to electrical boxes or enclosures. Includes steel locknut and gasket. NEMA/ANSI FB-1 compliant.

• Compression EMT Connector, Steel, 1"
• For Use With-Join EMT To Box or Enclosure
• Raintight and concrete tight connection

Product Highlights

Steel compression EMT connector with insulated throat, raintight and concrete tight connection, and includes steel locknut and gasket.

Product Information

Standard Information

• Brand: TOPAZ
• Manufacturer Part Number: 653SIRT
• Country of Origin: CHN

Technical Specifications

• Type: Compression
• Throat Type: Insulated
• Trade Size: 1 Inch
• Diameter: 0.562 Inch
• Length: 0.846 Inch
• Material: Zinc Plated Steel
• Constructional Feature: Rain/Concrete Tight
• Used On: EMT Conduit
• Includes: Steel Locknut and Gasket
• Applicable Standard: NEMA/ANSI FB1
• Brand Name: Topaz
• Brand Part Number: 653SiRT
• Item UPC: 751338830080
• Manufacturer: Topaz
• Manufacturer Part Number: 653SIRT
