Topaz 1573HDG 1In Edge Type Conduit Support Hot Dip Galvanized

Product Description

The Topaz 1573HDG is a one-inch edge type conduit support designed to provide reliable mounting for electrical conduits. This support is made from galvanized steel and features a hot-dip galvanized finish for enhanced durability and corrosion resistance. The design allows for easy installation of electrical conduits parallel to a beam or channel, making it suitable for various applications in electrical installations.

• Supports EMT or rigid conduits
• Hot-dip galvanized for durability
• One mounting hole for quick installation

Product Highlights

This conduit support is ideal for mounting various types of conduits and offers a solid support mechanism. Its hot-dip galvanized finish ensures long-lasting performance in different environmental conditions.

Product Information

Standard Information

• Brand: Topaz
• Manufacturer: Topaz
• UPC: 75133886563
• WES Product Code: 2963065558

Technical Specifications

• Type: Edge Type Conduit Support
• Size: 1 In
• Material: Galvanized Steel/Iron
• Weight: 0.74
• Mounting: Bolt
• Finish: Hot-Dip Galvanize
• Standard: UL File Number E174011; ASTM A123/123M; RoHS Compliant; NEMA FB1; Federal Spec A
• Application: Mount EMT or Rigid Conduits Parallel to a Beam; Channel or Angle Supports
• Number Of Holes: 1
