Product Description
The TITAN PRO TRCFD505 is a motor dual run capacitor with a rating of 50/5 MFD and 370-440V. It features a hermetically sealed aluminum case with a steel cover and is built to meet international standards for AC motor run capacitors. This capacitor is suitable for HVAC applications and electric motors.
- Capacitance: 50/5 MFD
- Voltage: 370-440 VAC
- Round shape with 2-1/2" diameter
Product Highlights
This motor dual run capacitor is designed for reliable performance and long operational life in various motor applications.
Product Information
Standard Information
-
Brand: TITAN PRO
-
Manufacturer Part Number: TRCFD505
-
Country of Origin: China
Technical Specifications
-
Voltage: 440/370V AC
-
Brand: TITAN PRO
-
MPN: TRCFD505
-
Capacitor Voltage: 370-440VAC
-
Diameter: 2-1/2"
-
Capacitor Shape: Round
-
Part Number: TRCFD505
-
Category: HVAC
-
Subcategory: Capacitor Motor Starter
-
Frequency: 60/50 Hz
-
Capacitance: 50+5MFD / 5%
-
Type: Running Capacitor
-
Compliance: NO-PCB, ROHS Compliant
-
MFD: 50/5
-
Shape: Round
-
Product Type: Capacitor
-
Hz: 60/50
-
Item: Motor Dual Run Capacitor
-
Standards: IEC 60252-1:2001
-
Case Height: 3 15/16 in
-
EIA UL Base: A
-
Temp. Range: -40 Degrees to 70 Degrees C
-
For Use With: Electric Motors
-
Case Material: Aluminum
-
Overall Depth: 2 1/2 in
-
Overall Width: 2 1/2 in
-
Terminal Type: 1/4 in Male Quick-Connect
-
Cover Material: Steel
-
Overall Height: 4 7/16 in
-
Connection Type: Quick Connect
-
Terminal Gender: Male
-
Max. Temperature: 70 Degrees C
-
Min. Temperature: -40 Degrees C
-
Number of Pieces: 1.0
-
Microfarad Rating: 50/5
-
EIA Tolerance Code: A
-
Terminal Tab Width: 1/4 in
-
Number of Terminals: 3.0
-
Motor Capacitor Type: Motor Dual Run Capacitor
-
Terminal Designations: Standard
-
Capacitor Voltage Group: 440V AC
-
Capacitor Voltage (Merch): 440V AC
-
Model: TRCFD505
-
UPC: 0840899104669
-
Country of Origin: China
