Titan Pro TRCFD4075 Round Motor Dual Run Capacitor 40/7.5 Microfarad Rating 370-440VAC Voltage

Product Description

The TITAN PRO TRCFD4075 is a round motor dual run capacitor with a 40/7.5 microfarad rating and 370-440VAC voltage. This capacitor contains two capacitance values in a single unit and can replace two single run capacitors. It can connect to two motors, such as a blower and compressor in HVAC applications.

• Round shape
• Contains two capacitance values in a single unit
• Can replace two single run capacitors

Product Highlights

Dual run motor capacitors with two capacitance values in a single unit. Ideal for HVAC applications.

Product Information

Standard Information

• Brand: TITAN PRO
• Manufacturer Part Number: TRCFD4075
• Country of Origin: China

Technical Specifications

• Maximum Voltage: 440 Volts
• Brand: TITAN PRO
• MPN: TRCFD4075
• UPC: 840899104621
• Manufacturer: Titan Pro
• Product Type: Dual Run Capacitor
• Microfarad Rating: 40/7.5
• Voltage: 370-440V AC
• Hz: 60/50
• Shape: Round
• Case Material: Aluminum
• Cover Material: Steel
• Terminal Type: 1/4" Male Quick-Connect
• Temp. Range: -40 Degrees to 70 Degrees C
• Case Height: 3-3/8"
• Diameter: 2-1/2"
• Overall Width: 2-1/2"
• Overall Height: 3-7/8"
• EIA UL Base: T
• Overall Depth: 2-1/2"
• Item: Motor Dual Run Capacitor
• Motor Capacitor Type: Motor Dual Run Capacitor
• MFD: 40/7.5
• Volts: 440/370
• Housing Shape: Round
• Overall Diameter: 2-1/2 in
• Housing Height: 3-3/4 in
• Operating Temperature - Minimum: -40 °C
• Operating Temperature - Maximum: 70 °C
• Frequency: 60/50 Hz
• Standards: IEC 60252-1:2001
• Terminal Gender: Male
• Terminal Tab Width: 1/4 in
• Number of Pieces: 1
• Terminal Connection Type: Quick Connect
• Number of Terminals: 3
• Sub-brand: Titan Pro
• EIA Tolerance Code: A
• UNSPSC: 32121501
