Product Description
The Titan HD PRCFD4575A is a USA-made capacitor designed to provide contractors with confidence. It features a substantial 60,000 hours of operating life and meets the rigorous EIA-456-A industry standard for performance and quality. Contains metalized polypropylene film technology for self-restoration and a UL-approved pressure sensitive interrupter.
- Made in USA
- 60,000 hours operating life
- Meets the rigorous EIA-456-A industry standard for performance and quality
Product Highlights
This Titan HD capacitor has metalized film technology for self-restoration and environmentally-friendly oil that prevents corrosion.
Product Information
Standard Information
-
Brand: TITAN HD
-
Manufacturer Part Number: PRCFD4575A
-
Country of Origin: USA
Technical Specifications
-
MFD: 45/7.5
-
Shape: Round
-
Voltage: 440/370V
-
Product Type: Capacitor
-
Type: Run Capacitor, Round, Dual Section
-
Used On: Motor
-
Brand: Titan HD
-
Cycle/Hertz: 50/60 Hz
-
Prop 65: true
-
Capacitor Type: Run
-
Country of Origin: USA
-
Capacitor MFD µF: 45/7.5
-
Capacitor: Run
-
Volts: 370_440
-
Material: Aluminum
-
Hertz: 50_60
-
Capacitance: Dual
-
MFD Rating: 45 + 7.5
-
Operating Life: 60000 Hour
-
Operating Temperature Rating: -40 to 70 Deg C
-
Can Size: 2 Inch Diameter x 3.84 Inch Height
-
Can Material: Aluminum
-
Oil Type: Soybean Based
-
Terminal Type: Standard blade
-
Tolerance: +/-5 Percent
-
Applicable Standard: EIA 456-A, UL, UL (Canada and US)
