Titan Hd POCF30A Motor Run Capacitor, 30 MFD, 440V, Oval

Product Description

The TITAN HD POCF30A is a motor run capacitor with a 30 microfarad rating and 440V voltage. It features an oval shape and operates at 60/50 Hz. The capacitor's case is made of aluminum, with a steel cover. It is suitable for various motor applications requiring a reliable capacitor.

• Microfarad Rating: 30
• Voltage: 440V
• Terminal Type: 1/4 In. Male Quick-Connect
• Temperature Range: -40 Degrees to 70 Degrees C

Product Highlights

This motor run capacitor is designed for durability and performance, meeting industry standards for quality and safety.

Product Information

Standard Information

• Brand: TITAN HD
• Manufacturer Part Number: POCF30A
• Country of Origin: USA

Technical Specifications

• Microfarad Rating: 30
• Voltage: 440V
• Frequency: 60/50 Hz
• Shape: Oval
• Case Height: 3-7/8 In.
• Overall Height: 4-3/8 In.
• Overall Width: 2 In.
• Overall Depth: 1-1/4 In.
• EIA UL Base: A
• Terminal Type: Blade
• Temperature Range: -40 Degrees to 70 Degrees C
• Case Material: Aluminum
• Cover Material: Steel
• Standards: E136401, RoHS Compliant, IEC 60252
• MFD: 30
• Product Type: Capacitor
• Capacitance: 30 uF
• Voltage Rating: 440/370 V
• Standards/Approvals: RoHS Compliant, UL Listed
• Frequency Rating: 50/60 Hz
• Material: Aluminum Can
• Oil Type: Soybean-Based
• Tolerance: +/-5 %
• Rated Voltage: 370/440
