Timken YCJM3 Four Bolt Ball Flange Unit | 3 in Bore 5.51 in OD

Product Description

The Timken Fafnir YCJM3 is a four bolt ball flange unit designed to provide reliable performance. This unit combines the bearing, housing, seal, and locking system for straightforward installation and operation. It is suitable for various applications where high durability and efficiency are required.

• Each unit comes assembled and ready for mounting.
• Self-aligning ball bearings compensate for shaft misalignment.
• Factory prelubricated with a grease fitting for maintenance.

Product Highlights

Timken Fafnir housed units focus on reducing downtime while maximizing equipment performance. This unit is engineered to handle demanding conditions effectively.

Product Information

Standard Information

• Brand: Timken
• Part Number: YCJM3T

Technical Specifications

• Type: Wide Inner Ring Ball Bearing Insert
• Bore Diameter: 2.9997 inches | 76.19238 mm
• Overall Width: 7.750 inches | 196.85 mm
• Overall Height: 3.576 inches | 90.8304 mm
• Overall Length: 7.75 inches | 196.85 mm
• Outside Diameter: 5.51181 inches | 140 mm
• Static Load Capacity: 12200 lb
• Dynamic Load Capacity: 17900 lb
