Timken NAU4LKBF207-23 Flange-Mount Ball Bearing Unit - 1-7/16 in Bore - 4-Bolt Flange Mount - Adapter Mounted Locking

Product Description

The Timken NAU4LKBF207-23 is a flange-mount ball bearing unit designed for secure and effective operation. This unit features a bore size of one and seven-sixteenths inches and includes a four-bolt flange mount. It is equipped with a locking sleeve for adapter mounting.

• Wide inner ring design
• Polymer housing material
• Self-aligning for ease of installation

Product Highlights

This product is suitable for fixed applications, enhancing overall reliability and reducing maintenance needs.

Product Information

Standard Information

• Country of Origin: USA
• Minimum Order Quantity: 1

Technical Specifications

• Weight: 1.4 lbs
• Bore Diameter: 1-7/16 in
• Housing Width: 1.223 in
• Overall Width: 5.1250 in
• Overall Height: 1.8200 in
• Overall Length: 4.7530 in
• Type of Bearing: Ball
• Number of Mounting Holes: 4
• Bolt Circle Diameter: 0.5313 in
• Length Through Bore: 1.685 in
• Adapter Sleeve: Locking Sleeve
• Bolt Center to Center Length: 3.6250 in
• Self Aligning: Yes
