Timken Co. 473336 Dual Lip with One Spring

Product Description

The Timken Co. 473336 is a dual lip shaft seal designed for various applications. This shaft seal is optimal for ensuring a perfect fit and reliable performance. It features a single spring mechanism to maintain sealing pressure effectively.

• 1.720 inches shaft diameter
• 2.561 inches housing bore
• Internal seal design with dual lip

Product Highlights

This seal is engineered to provide excellent sealing capability with a bonded design.

Product Information

Standard Information

• Brand: Timken Co.
• Part #: 100754577

Technical Specifications

• Temperature Range [Max]: 225 °F
• Temperature Range [Min]: -40 °F
• Shaft Diameter: 1.72 inches
• Housing Bore Diameter: 2.561 inches
• Pressure: 7 psi
• Lip Type: Dual Lip with One Spring
• Lip Material: Nitrile
• Spring Material: Carbon Steel Garter
• Surface Speed [Nom]: 3,000 ft/min
• Seal Application: General Purpose
• Cover/Compensation Ring/Plate Required: No
• Weight: 0.07 LB
• EAN or UPC: 53893494210
