Timken Co. 471984 Dual Lip with One Spring 1.75 In 3 In 471984

Product Description

The Timken Co. 471984 Dual Lip with One Spring is a shaft seal designed for effective sealing in various industrial applications. This product features a shaft diameter of one and three-quarters inches and a housing bore diameter of three inches. It provides reliable sealing due to its nitrile lip material and bonded design, ensuring durability and performance.

• Shaft diameter of one and three-quarters inches
• Housing bore diameter of three inches
• Temperature range from negative forty to two hundred twenty-five degrees Fahrenheit

Product Highlights

This seal is optimal for general-purpose applications, effectively handling pressures up to seven psi with a surface speed of three thousand feet per minute.

Product Information

Standard Information

• Brand: Timken Co.
• Part Number: 100754461

Technical Specifications

• Lip Style: Internal
• Misalignment & Runout: 0.015@800, 0.010@4200
• Seal Design: Bonded Design
• Pressure: 7 psi
• Seal Application: General Purpose
• Temperature Range [Max]: 225 °F
• Lip Material: Nitrile
• Spring Material: Carbon Steel Garter
• Housing Bore Diameter: 3 in
• Case Construction: Steel Case w/o Inner Case
• Surface Speed [Nom]: 3,000 ft/min
• Construction: 47
• Shaft Diameter: 1.75 in
• Lip Type: Dual Lip w/One Spring
• Temperature Range [Min]: -40 °F
• Weight: 0.094 LB
• EAN or UPC: 53893493008
