Timken 22340EMBW33W45AW800C4 Spherical Roller Bearing 200 mm ID 420 mm OD

Product Description

The Timken 22340EMBW33W45AW800C4 is a spherical roller bearing designed for high load capacities. This bearing features a bore diameter of two hundred millimeters and an outside diameter of four hundred twenty millimeters. It is constructed with a machined brass cage and is intended for vibratory applications.

• Enhanced surface finishes for improved longevity
• Optimized internal geometry for maximum load carrying
• Standard lubrication grooves and holes in the outer ring

Product Highlights

This spherical roller bearing is suitable for a range of industrial applications, ensuring smooth operation under demanding conditions.

Product Information

Standard Information

• Brand: Timken
• Manufacturer Catalog No: 00835

Technical Specifications

• Series: 223
• Weight: 204.78 lbs
• Overall Width: 138 mm
• Cage Material: Brass Cage
• Bore Type: Straight
• Closure Type: Open
• Operating Temperature Range: -65 to +392 °F
• Maximum RPM: 1100 rpm
