Time Mark 360-H-1MIN Digital Input Time Delay Relay, 40-260V AC/DC, 1 to 1023 Minutes

Product Description

The Time Mark Signaline 360-H-1MIN is a digital input time delay relay designed for various applications such as HVAC systems and machine tool control. It operates in a timing range from one to one thousand twenty-three minutes and is rated for coil voltages of forty to two hundred sixty volts AC/DC.

• Timing range: 1 to 1023 minutes
• Voltage range: 40 to 260V AC/DC
• DPDT contact form with a relay contact of 10 Amps @ 240VAC

Product Highlights

This relay is suitable for industrial applications, providing reliability and flexibility with its adjustable time settings.

Product Information

Standard Information

• Product Name: Time Mark Signaline 360-H-1MIN
• UPC: 66291700562

Technical Specifications

• Application: Automatic, Machine Tool Control Circuit, HVAC Circuit, Warm-Up Delay Circuit
• Coil Voltage: 40 to 260 VAC/VDC
• Contact Form: DPDT
• Dimensions: 2.44 in H x 1.75 in W x 3.42 in D
• Mounting Type: Socket
• Number of Pins: 8
• Operation Mode: Operate Delay
• Temperature Rating: -20 to 140 deg F
• Time Setting: 1 to 1023 min
• Series: 360 Series
• Standards/Approvals: UL Recognized, cCSAus Certified
