Tillman 635300 Arcshield Vinyl Strip Curtain 8in 300ft Roll

Product Description

The TILLMAN 635300 ArcShield is a bronze-tinted transparent vinyl strip curtain designed for use in welding, fabrication, and industrial environments where arc flash protection and visibility are both required. The curtain is constructed from a series of interlocking, flame-resistant, heavy-duty vinyl strips, each measuring 8 inches in width and 0.08 inches in thickness. The roll measures 300 feet in length, providing enough material for large or multiple installations. This product is typically installed by welding shop supervisors, industrial safety personnel, or maintenance contractors responsible for workstation separation and arc protection compliance.

The TILLMAN 635300 is suited for use in welding booths, fabrication bays, and manufacturing facilities where a durable, see-through barrier is needed to shield nearby workers from arc flash, spatter, and UV exposure without eliminating sightlines. The interlocking strip design allows personnel and equipment to pass through without removing the curtain. The bronze tint provides optical filtering appropriate for arc welding environments. For narrower or thicker strip requirements, related options include the 637-200 in 12-inch width at 0.12-inch thickness, and the 635R for custom lengths.

Key Features

• Bronze-tinted transparent vinyl provides arc flash and UV filtering with maintained visibility
• Flame-resistant, heavy-duty vinyl construction rated for welding environments
• Interlocking strip design allows hands-free pass-through for personnel and equipment
• 8-inch strip width with 2-inch partial overlap and 3-inch full overlap options
• 300-foot roll length suits large installations or multiple workstation setups
• Compatible with related ArcShield accessories and custom-length roll option 635R

Compatibility

Designed for use with standard vinyl strip curtain mounting hardware in welding booths and industrial workstation divider applications. Related ArcShield configurations include the 637-200 (12-inch width, 0.12-inch thickness, 200-foot roll) and the 635R custom-length roll.

Installation Notes

Installation is typically performed by maintenance personnel or industrial safety contractors using standard hardware and hand tools. Strips should be hung from appropriate overhead mounting brackets rated for the curtain weight and span. Verify that all mounting hardware is secured to structural supports before loading the curtain. Follow applicable OSHA and ANSI Z49.1 safety standards for welding area barrier requirements when planning the installation layout.

Technical Specifications

• Strip Width: 8 inches
• Strip Thickness: 0.08 inches
• Roll Length: 300 feet
• Partial Overlap: 2 inches
• Full Overlap: 3 inches
• Tint: Bronze
• Material: Flame-resistant vinyl

Standard Information

• Brand: TILLMAN
• Manufacturer Part Number: 635300
