Tigre Usa Inc 1406-007 Poly Insert Elbow 3/4 Inch

Product Description

The TIGRE USA INC 1406-007 is a 3/4 inch poly insert elbow fitting designed for use with PE polyethylene pipe in cold water distribution applications. This fitting creates a 90-degree directional change in a polyethylene line and connects using stainless steel clamps over the barbed insert ends. It is rated for potable water service under NSF 14 and NSF 16 and meets ASTM D-2609 standards. Plumbers and irrigation contractors install this fitting where underground or surface-run poly pipe requires a directional transition. It is sold in a package quantity of 50 units per carton.

This elbow is suited for residential and light commercial cold water service lines, well water systems, irrigation laterals, and agricultural water distribution where polyethylene pipe is the specified material. It is a poly-by-poly configuration, meaning both ends accept polyethylene pipe. It is not approved for use inside a dwelling, and must not be used with compressed air or any gas service. Application is restricted to cold water only.

Key Features

• 3/4 inch barbed poly insert ends for secure connection to PE polyethylene pipe
• Stainless steel clamp-style connection method for leak-resistant assembly
• NSF 14 and NSF 16 listed for potable cold water service
• ASTM D-2609 listed construction
• Not for use with compressed air, gases, or inside dwelling units
• Sold in a 50-piece package quantity

Compatibility

Designed for use with PE polyethylene pipe in cold water service applications. Both ends are poly insert configuration requiring stainless steel clamps for connection. Not compatible with gas, compressed air, or indoor plumbing within a dwelling.

Installation Notes

Installation is performed by licensed plumbers or irrigation technicians. Shut off and depressurize the water line before cutting or fitting. Slide stainless steel clamps onto the pipe before inserting the fitting ends, then position clamps over the barbed insert and tighten to manufacturer specifications using a clamp tool or screwdriver. Do not modify the fitting in any way, as fitting modifications void the warranty.

Technical Specifications

• Size: 3/4 inch
• Connection Type: Poly Insert x Poly Insert
• Pipe Compatibility: PE Polyethylene pipe
• Service: Cold water only
• Standards: ASTM D-2609, NSF 14, NSF 16
• Weight: 3 pounds
• Package Quantity: 50 each

Standard Information

• Brand: TIGRE USA INC
• Manufacturer Part Number: 1406-007
