Thomas Betts HS12-6LR Heat Shrink Sleeve 3:1 Red 6in

Product Description

The THOMAS BETTS HS12-6LR is a red polyolefin heat shrink sleeve designed to protect wire terminations, splices, and cable bundles in electrical and low-voltage wiring applications. Starting at 0.5 inches inner diameter and shrinking down to 0.15 inches at a 3:1 ratio, it delivers a tight, conforming fit over a wide range of wire gauges. At 6 inches in overall length, this sleeve provides ample coverage for most field termination work. The polyolefin construction resists abrasion, acid, and corrosion, making it suitable for demanding environments. Heat activation occurs at 248 degrees F, and the sleeve maintains performance up to a maximum operating temperature of 194 degrees F. Licensed electricians and low-voltage technicians are the primary installers.

This heat shrink sleeve is suited for residential and commercial electrical installations where wire insulation, strain relief, or environmental sealing is needed. Compatible with wire sizes ranging from 8 AWG to 6 AWG, it works well for branch circuit wiring, control wiring, and panel connections where a secure, color-coded sleeve is required. The red color aids in visual identification of specific wire runs or phases during installation and future service calls. Each package contains 25 sleeves, sold in a minimum order quantity of 1.

Key Features

• 3:1 shrink ratio provides tight, conforming fit from 0.5 inches ID down to 0.15 inches ID
• Polyolefin construction resists abrasion, acid, and corrosion
• 6 inches overall length gives ample coverage for terminations and splices
• Compatible with 8 AWG to 6 AWG wire sizes
• Red color supports visual wire identification in the field
• UL Listed and CSA Certified for use in code-compliant installations

Compatibility

Designed for use with 8 AWG to 6 AWG conductors. Suitable as an OEM-style heat shrink solution for electrical wire protection and insulation in residential and commercial wiring systems.

Installation Notes

Installation is performed by licensed electricians or qualified low-voltage technicians. De-energize all circuits before applying the sleeve to any conductor or termination. Use a heat gun calibrated to deliver sufficient airflow at or above the 248 degrees F activation temperature, applying heat evenly around the sleeve to achieve uniform shrinkage. Avoid open-flame tools, which can scorch or unevenly shrink polyolefin tubing.
