Thomas Betts ALB-6 Lb Conduit Body 2 Inch Imc Rigid Aluminum

Product Description

The THOMAS BETTS ALB-6 is a 2-inch trade size LB-style conduit body designed for use with IMC and rigid aluminum conduit systems. The oval-shaped aluminum body provides a pull, splice, or direction-change point within a conduit run. It carries a 69.5 cubic inch (cc) volume capacity and measures 9-13/16 inches overall length. Electricians install this fitting where a 90-degree change of direction is needed while maintaining access to conductors through the removable cover. The gray aluminum construction is weather resistant and suitable for exposed or concealed raceway installations.

This LB conduit body is rated for use with 2-inch IMC and rigid metal conduit. Typical applications include commercial and industrial electrical distribution systems, service entrances, exposed conduit runs on building exteriors or interiors, and anywhere a back-entry, bottom-exit pull point is required. The weather-resistant rating makes it appropriate for wet and damp locations where conduit systems are subject to outdoor exposure or wash-down environments.

Key Features

• LB configuration for 90-degree direction change with back entry and bottom exit
• 2-inch trade size compatible with IMC and rigid metal conduit
• 69.5 cubic inch (cc) volume capacity for conductor fill compliance
• Oval body shape with 9-13/16 inches overall length
• Weather-resistant aluminum construction in gray finish
• UL Listed (File E28688) and RoHS Compliant

Compatibility

Designed for use with 2-inch trade size IMC and rigid aluminum or steel conduit systems. Compatible with standard conduit hubs, locknuts, and fittings rated for 2-inch trade size.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize all circuits before opening or working within any conduit body. Ensure conductor fill does not exceed the 69.5 cc volume capacity as required by NEC Article 314. The removable cover must be accessible after installation and should be secured with the appropriate fasteners before returning the system to service.
