The Unico System M2430BL1-EC2 M2430BL1-EC2 2.0-2.5 Ton Blower Module

Product Description

The THE UNICO SYSTEM M2430BL1-EC2 is a 2.0-2.5 ton left hand 208/230v ECM blower module. The variable speed EC Motor has the best efficiency and control and removes up to 4X more humidity. It features balanced blower wheels for smooth, vibration-free operation and a direct drive motor for improved efficiency. Optimized for zone damper systems, it ensures efficiency and sound.

• Variable speed EC Motor for efficiency and control
• Removes up to 4X more humidity
• Quietest option

Product Highlights

This blower module is designed for smooth operation, improved efficiency, and optimal performance in various applications.

Product Information

Standard Information

• Brand: THE UNICO SYSTEM
• Manufacturer Part Number: M2430BL1-EC2

Technical Specifications

• Product code: M2430BL1-EC2
• Manufacturer: Unico
• SKU: M2430BL1-EC2
• Model Series: M-Series
• Motor Type: EC2 Variable Speed
• Unico Model: 2430
• Power Supply: 208-230/1/60
• Brand: Unico
• Installation Orientation: Horizontal, Vertical Upflow
• Certifications: UL
• Tonnage: 2.0-Ton, 2.5-Ton
• Motor CFM @ 1.5" E.S.P.: 600
• Motor HP and RPM: 1/2 HP 1700
