Tecumseh AE1198E-215-J7 115v 1ph 2852 btu R134a compressor 1/4 inches odf x 3/8 inches flare (SAE)

Product Description

The TECUMSEH AE1198E-215-J7 is a reciprocating compressor designed for high temperature applications. Operating on 115V 1 phase power, it utilizes R-134A refrigerant and offers a capacity of 2852 BTU. This standard efficiency unit is suitable for high/commercial back pressure (HBP/CBP) systems, featuring a 1/4 HP motor with low start torque.

• Reciprocating type compressor for high temperature applications.
• Operates on 115V 1 phase power with R-134A refrigerant.
• Provides 2852 BTU capacity, suitable for HBP/CBP systems.

Product Highlights

This compressor features a 1/4 HP motor, low start torque, and 3/8 inch flare suction line.

Product Information

Standard Information

• Brand: TECUMSEH
• Manufacturer Part Number: AE1198E-215-J7
• Country of Origin: France

Technical Specifications

• Compressor Type: Standard Efficiency Reciprocating
• Phase: 1
• Voltage: 115V 1 Phase 60Hz
• Application: HBP/CBP - High/Commercial Back Pressure
• BTU Capacity: 2852 BTU
• Refrigerant: R-134A
• Country of Origin: France
• Horsepower: 1/4 HP
• Start Torque: Low Start Torque (LST)
• Suction Line Size: 3/8" FLARE (SAE)
• Discharge Line Size: 0.250" Sweat (1/4" ODF)
• Motor Type: Induction Run (RSIR/CSIR)
