Teco GP0036G General Purpose Motor 3 HP 1200 RPM 213T Frame 208/230/460 Volt

Product Description

The Teco GP0036G is a 3 HP electric motor designed for various industrial applications. This three-phase motor operates at 1200 RPM and can handle voltage requirements of 208, 230, and 460 Volts. It features a Totally Enclosed Fan Cooled (TEFC) design that ensures longevity and efficiency.

• Three-phase, 3 HP, 1200 RPM motor
• TEFC enclosure for durability
• Suitable for HVAC equipment, pumps, and compressors

Product Highlights

Built with a robust rolled steel frame, this motor provides reliable performance across a range of environments. Its high efficiency and effective power factor make it a great choice for demanding applications.

Product Information

Standard Information

• MPN: GP0036G
• Manufacturer: TECO-Westinghouse

Technical Specifications

• Horsepower: 3 HP
• Frame Size: 213T
• Speed: 1200 RPM
• Voltage: 208/230/460 Volts
• Amperage: 9.23 A
• Service Factor: 1.15
• Efficiency: 89.5% Full Load
• Power Factor: 68% Full Load
