TECO NP7/52 AC Motor 7.5 HP 230/460V

Product Description

The TECO NP7/52 is a three-phase AC motor suitable for diverse applications like fans, pumps, crushers, compressors, mixers, and conveyors. This motor features a totally enclosed fan cooled (TEFC) design, ensuring protection from external conditions. The cast iron frame and end brackets add durability, while the rolled steel fan cover enhances cooling efficiency.

• Rated for 7.5 HP at 3600 RPM
• Operates on 208-230/460 Volts at 60 Hz
• Designed for inverter duty and CSA certified for Class I Div. 2 Groups B C D - Temp Code T3C

Product Highlights

The TECO NP7/52 motor is designed to operate efficiently in a variety of environments. Its robust construction and versatile voltage options provide reliable performance for heavy-duty tasks.

Product Information

Standard Information

• Brand: Teco-Westinghouse
• MPN: NP7/52

Technical Specifications

• Horsepower: 7.5
• Speed: 3600 RPM
• Voltage: 208-230/460V
• Phase: 3
• Frame Size: 213T
• Enclosure Type: TEFC
• Full Load Efficiency: 91%
• Full Load Power Factor: 89%
• Full Load Amperage: 8.67A
• Service Factor: 1.15 (Continuous); (1.0 @ 50 Hz)
• Ambient Temperature: Designed for 40°C
• Elevation: Designed for 3300 ft.
• Rotation: Bi-Directional
• Mounting Type: Foot Mount
• Duty: Vector Duty
