TECO NP0034C AC Motor 3 hp 182T

Product Description

The TECO NP0034C is a three-phase AC motor with a horsepower of three and a speed of eighteen hundred RPM. This motor has a frame size of 182T and supports both footed and C-face mounting. The design includes a totally enclosed fan cooled (TEFC) enclosure and features a durable cast iron frame.

• Three-phase operation for enhanced performance
• Suitable for both 60 Hz and 50 Hz applications
• NEMA Premium efficiency compliant

Product Highlights

Built for efficiency and reliability, the TECO NP0034C motor meets NEMA Premium efficiency standards and is available for Class I, Division II, Groups B, C, and D environments with a temperature code of T3C.

Product Information

Standard Information

• Brand: TECO
• MPN: NP0034C

Technical Specifications

• Motor Type: AC Motor
• Phase: Three Phase
• Horsepower: 3 hp
• RPM: 1800
• Frame: 182T
• Mounting Type: Footed, C Face
• Enclosure: TEFC
• Efficiency: Premium Efficiency
• Input Voltage: 208/230/460V
• Frequency: 60 Hz
• Full Load Amps: 3.74
• Service Factor: 1.15
• Insulation Class: Class F
• Ambient Temperature: 40C
• Ingress Protection: IP54
• NEMA Design: B
• Frame Material: Cast Iron
• Weight: 137 lb
• Duty: S1
• Rotor: Die Cast Aluminum
• Full Load Speed: 1755
• Locked Rotor Torque: 225
• Breakdown Torque: 300
• Locked Rotor Current: 32
• Rotor Inertia lb ft: 0.367
• Speed Range CT: 10:01
• Speed Range VT: 20:01
• NEMA Standards: NEMA MG1, Part 31.4.4.3
• Flange: C-Flange
• Poles: 4
