TECO EP0154 15 HP AC Motor 1800 RPM 254T Frame

Product Description

The TECO EP0154 is a three-phase AC motor designed for severe duty applications. This model features a durable cast iron frame and is equipped with end brackets and a fan cover. It is totally enclosed and fan cooled (TEFC), suitable for high-temperature environments, and is compatible with inverter duty applications. Its construction ensures reliable operation up to forty degrees Celsius ambient temperature and at elevations reaching three thousand three hundred feet.

• Cast iron frame for durability.
• Designed for severe duty applications.
• Suitable for inverter duty use.

Product Highlights

This motor is U.L. Recognized, CSA Approved, and CE Marked, providing assurance of quality and safety standards.

Product Information

Standard Information

• Brand: TECO
• MPN: EP0154

Technical Specifications

• Horsepower: 15 hp
• Kilowatts: 11.2 kW
• RPM: 1800 RPM
• Number of Poles: 4
• Frame: 254T
• Voltage: 208-230/460V
• Frequency: 60 Hz
• Phase: 3
• Enclosure: TEFC (Totally Enclosed Fan Cooled)
• IP Rating: IP55
• Service Factor: 1.15
• Insulation Class: Class F
• Inverter Duty: Yes
• Approvals: CE, CSA, UL
• Mounting Type: F1 Mount
• Frame Material: Cast Iron
• Bearings: Ball Bearings
• Rotation: Reversible
• Ambient Temperature: 40 degrees C
• Shaft: 4 x 1 5/8 Dia. Keyed Shaft
• Net Weight: 360 lbs
