TECO E510-210-H3-U Variable Frequency Drive

Product Description

The TECO E510-210-H3-U is an AC variable frequency drive, also known as a VFD. This unit is designed for controlling motor-driven applications, providing flexibility for both permanent magnet and induction motors. The detachable keypad with a speed potentiometer enhances user experience. This drive is ideal for many applications including conveyors, fans, and pumps.

• Enclosure rated at IP20/NEMA 1
• Built-in PLC functionality
• Suitable for a variety of industrial applications

Product Highlights

The TECO E510-210-H3-U supports robust motor control for various industrial needs, ensuring efficiency and reliability.

Product Information

Standard Information

• Manufacturer: TECO-Westinghouse
• Model: E510

Technical Specifications

• Horsepower: 10 HP
• Input Voltage: 200-240V, 3 Phase
• Output Voltage: 0-240V, 3 Phase
• Output Current: 35 amps
• Enclosure: NEMA 1/IP20
• Dimensions (HxWxD): 10.27 inches x 7.36 inches x 7.98 inches
• Weight: 14.3 lbs
• Certification: UL, cUL, and CE Approved
