Techtop Industries GR3-CI-TF-182T-4-B-D-3 AC Motor 3 HP 182T Frame

Brand: TECHTOP INDUSTRIES
SKU: GR3-CI-TF-182T-4-B-D-3
Availability: Out Of Stock
$719.51
$719.51
LTL Delivery

This product weighs 94 lb each and will be shipped via LTL carrier. A lift gate option will be added free of charge for your convenience.

HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The TECHTOP INDUSTRIES GR3-CI-TF-182T-4-B-D-3 AC motor features a NEMA premium cast iron construction, allowing for smooth substitutions of traditional rolled steel and cast iron NEMA frames. This motor is suitable for a diverse range of applications in both commercial and industrial markets. Rated at 3 HP, 1800 RPM, and 230/460V, this motor is EISA compliant.

  • NEMA Premium Energy Efficiency Design
  • MG1 Part 31 Compliant for VFD use (15:1 CT)
  • 2-Part Epoxy Coating - IP 55 Ingress Protection

Product Highlights

This Techtop motor features a class H Stator, TEFC enclosure, and a rigid mount. Suitable for industrial applications.

Product Information

Standard Information

  • Brand: TECHTOP INDUSTRIES
  • Manufacturer Part Number: GR3-CI-TF-182T-4-B-D-3
  • Country of Origin: China
Technical Specifications
SKU
GR3-CI-TF-182T-4-B-D-3
Enclosure Type
Totally Enclosed Fan Cooled
Motor RPM
1800
Frame Size
182T
Horsepower
3 hp
Brand
Techtop
Mounting Type
Rigid
Phase
Three Phase
Electrical
208-230/460 Volts
Frequency Rating
60 Hz
Insulation Class
Class F
Material
Cast Iron
Service Factor
1.25
Temperature Rating
40 deg C
Torque Rating
21.80 lb-ft
Voltage Rating
230/480 VAC
Standard & Approvals
EISA Compliant, Class 1, Division 2, Groups A, B, C and D
Bearing Type
Ball
Speed
1800 RPM
Amperage Rating
7.95/3.97/9.6/4.8 A
Mounting
Rigid Base
Manufacturer
Techtop Industries, Inc
Full Load Amps
7.95/3.97
Inverter/Vector Duty Rating
Inverter Duty
Rated Load (HP)
3
AC Frequency Rating
60 Hz
Shaft Type
Keyed
AC Motor Type
Induction/Asynchronous
Shaft Diameter
1 1/8 in
IP Rating
IP55
Nominal Rated Input Voltage
230 V, 460 V
Model
GR3-CI-TF-182T-4-B-D-3
NEMA Frame Suffix
T
AC Phase
Three Phase
Enclosure
TEFC
Volts
230/460
Country of Origin
China
Reversible/Non-Reversible
Reversible
