Techtop BK3-CI-TF-284T-6-BR-G-15 Oil Pump Electric Motor - 15 hp - 230/460/796 V

Product Description

The Techtop BK3-CI-TF-284T-6-BR-G-15 is a durable oil pump electric motor designed for heavy-duty applications. This motor operates at fifteen horsepower, making it suitable for various industrial tasks. It features a TEFC enclosure and can function on multiple voltage ratings of two hundred thirty, four hundred sixty, or seven hundred ninety-six volts. The three-phase design allows for efficient operation and stability.

• 15 horsepower motor
• TEFC enclosure
• Versatile voltage ratings: 230/460/796 V

Product Highlights

This motor is ideal for machinery requiring reliable energy input, such as pumps or compressors. Its design is robust, ensuring long-term performance in demanding environments.

Product Information

Standard Information

• Brand: Techtop Industries
• Part Number: Q2534

Technical Specifications

• Amperage Rating: 38.2/19.1/11 A
• Bearing Type: Ball
• Enclosure Type: TEFC
• Frame: 284T
• Frequency Rating: 60 Hz
• Horsepower: 15 hp
• Insulation Class: F
• Material: Cast Iron
• Mounting Type: Rigid Base
• Phase: Three
• Service Factor: 1.15
• Shaft Size: 1-7/8 x 4-5/8 in
• Speed: 1200 rpm
• Voltage Rating: 230/460/796 V
