Techniks 84063-15/32 TG 100 15/32 Sealed Collet

Product Description

The Techniks 84063-15/32 TG 100 Sealed Collet is designed for precision. It is suitable for various machining applications and provides reliable coolant through capability.

• Clamping range of zero point four five three zero to zero point four six nine zero inches
• Accuracy TIR of zero point zero zero zero four inches
• Maximum coolant pressure of seven hundred fifty psi

Product Highlights

This sealed collet is essential for maintaining precision while working with coolant systems, ensuring a clean workspace and optimal operational conditions.

Product Information

Standard Information

• Brand: Techniks
• Part Number: 84063-15/32

Technical Specifications

• Size: 15/32
• Collet Series: TG100
• Clamping Range: 0.4530 - 0.4690 (11.509 - 11.906)
• Accuracy TIR: 0.0004
• Max Coolant PSI: 750
• Body Diameter: 1.379 inches
• Head Diameter: 1.379 inches
• Overall Length: 2-3/8 inches
• Clamping Hole Length: 2-3/8 inches
• Suitable For Use With: TG100 Series Toolholder and Coolant Ring
