Techniks 83868-5/8 SYOZ25 Single Angle Collet 5/8 Inch

Product Description

The TECHNIKS 83868-5/8 is a single angle collet in the SYOZ25 series, designed for precision workholding in CNC machining and toolholding applications. It accepts a 5/8 inch bore size and delivers a total indicator runout (TIR) of 0.0004 inches, making it suitable for operations where concentricity and repeatability are critical. The body diameter measures 1.38 inches and the overall length is 2.047 inches. Machinists and toolroom technicians install this collet into compatible SYOZ25 collet chucks to secure cutting tools or workpieces during milling, drilling, and light turning operations.

This collet is used in professional machine shop environments, including both production and job-shop settings. It fits into SYOZ25-series collet chucks mounted on CNC machining centers and manual milling machines. The 5/8 inch bore accommodates straight-shank tooling of that diameter. Its compact overall length suits applications where spindle clearance is a consideration. Installation is performed by qualified machinists or toolroom personnel following standard collet chuck assembly procedures.

Key Features

• SYOZ25 collet series for use with compatible SYOZ25 collet chucks
• 5/8 inch bore size accepts standard straight-shank tooling
• 0.0004 inch TIR for high concentricity and repeatable tool positioning
• 1.38 inch maximum body diameter fits SYOZ25 chuck specifications
• 2.047 inch overall length suits space-constrained spindle setups
• Lightweight at 0.1 pounds for minimal added mass in the toolholding assembly

Compatibility

Designed for use with SYOZ25-series collet chucks that accept single angle collets in the SYOZ25 specification. Verify chuck series and bore size before installation.

Installation Notes

Installation is performed by a qualified machinist or toolroom technician. Power down and de-energize the machine spindle completely before inserting or removing the collet. Use the appropriate collet nut and torque wrench designed for the SYOZ25 chuck system, following the chuck manufacturer's assembly guidelines. Inspect the collet and chuck bore for chips or damage before seating the collet to maintain the rated TIR.
