Techniks 22723 Precision Single End Face Mill Arbor 1 in 3-7/8 in OD CAT50

Product Description

The Techniks 22723 is a precision single end face mill arbor used in machining operations. This product has a one inch arbor size and an outside diameter of three and seven eighths inches, designed specifically for CAT50 taper systems. This arbor is compatible with all face mills, ensuring versatility in various applications.

• Provides H6 arbor tolerance for reduced chatter.
• Lab certified for accurate dimensions.
• Ground to AT3 taper for optimal spindle contact.

Product Highlights

This arbor is made from 8620 steel, ensuring durability and longevity during use.

Product Information

Standard Information

• Brand: Techniks
• Manufacturer: Techniks Industries

Technical Specifications

• Type: Precision Single End
• Taper: CAT50
• Arbor Size: 1 inch
• Outside Diameter: 3-7/8 inches
• Arbor Screw Diameter: 1.19 inches
• Pilot Length: 0.69 inches
• Face Contact Gage Length: 1.864 inches
• Gage Length: 2 inches
• Body Width: 2.2 inches
