Techniks 18851-05 Single Angle Collet Slimfit 6 5mm

Product Description

The TECHNIKS 18851-05 is a single angle collet in the SlimFIT 6 series, designed for precision toolholding in CNC machining centers and milling applications. With a collet size of 5.00 mm, an overall length of 1.417 inches, and a maximum body diameter of 0.394 inches, this collet delivers a total indicated runout (TIR) of 0.0001 inches. That level of runout accuracy supports tight-tolerance work where tool concentricity directly affects surface finish and tool life. Machinists and CNC setup technicians are the primary installers and users of this component.

The 18851-05 is suited for use in SlimFIT 6 compatible toolholding systems on CNC machining centers where slim-profile collet chucks are required. The slim body diameter of 0.394 inches makes this collet a practical choice for deep-cavity milling and applications with restricted spindle access. It is appropriate for both production and job-shop environments running small-diameter cutting tools in the 5.00 mm range.

Key Features

• 0.0001 inches TIR for high-precision tool concentricity
• 5.00 mm collet size for small-diameter tooling
• Slim body diameter of 0.394 inches for restricted-clearance applications
• Overall length of 1.417 inches for compact toolholding geometry
• Part of the SlimFIT 6 collet series for system compatibility

Compatibility

Designed for use with SlimFIT 6 series collet chucks and toolholding systems that accept single angle collets in this body diameter and collet size.

Installation Notes

Installation is performed by a machinist or CNC toolroom technician. The spindle must be fully stopped and the machine placed in an appropriate safe state before changing collets. Use the correct collet wrench and chuck nut specified for the SlimFIT 6 system. Inspect the collet bore and chuck taper for chips or debris before seating to protect TIR performance.
