Techniks 06042-10 Shrink-fit Tool Holder Adapter Taper Shank

Product Description

The TECHNIKS 06042-10 is a shrink-fit tool holder adapter designed for precision machining applications requiring secure, concentric tool retention. It features a taper shank with a 5/8-inch shank diameter and a 10-inch projection, making it well suited for deep-reach milling and drilling operations where extended reach and rigidity are critical. The nose diameter measures 0.48 inches, and the adapter supports through-coolant delivery for effective chip evacuation and tool life management at the cutting zone. This adapter is installed by CNC machinists and toolroom technicians working with shrink-fit tooling systems on machining centers.

This adapter is intended for use in machining center setups where extended projection is required to reach deep cavities, pockets, or features that standard-length holders cannot access. The through-coolant capability directs cutting fluid directly to the tool tip, improving performance in materials that generate significant heat during cutting. The 1/4-inch hole diameter accommodates compatible cutting tool shanks for shrink-fit retention. It is suited for production machining environments where tool runout and balance are closely controlled.

Key Features

• Taper shank design provides rigid, repeatable seating in compatible machine spindles
• 10-inch projection enables deep-reach machining of cavities and tall workpiece features
• Through-coolant support directs fluid to the cutting edge for improved thermal management and chip removal
• 5/8-inch shank diameter and 0.48-inch nose diameter suit standard shrink-fit tooling configurations
• 1/4-inch hole diameter for compatible cutting tool shank retention

Compatibility

Designed as an OEM-style shrink-fit tool holder adapter for use with compatible taper shank machining center spindles requiring extended-projection tooling.

Installation Notes

Installation requires an induction shrink-fit heating unit to thermally expand the holder bore before seating the cutting tool shank. Power down the machine and ensure the spindle is fully stopped before removing or installing any tooling. Allow the holder to cool completely and verify tool runout with a dial indicator before returning the spindle to operation. Follow the machining center manufacturer guidelines and applicable shop safety procedures when handling heated toolholders.
