Techniks 04547-11/16 Technik ER 40 11/16 Steel Sealed Collet

Product Description

The Techniks ER 40 11/16 Steel Sealed Collet, MPN 04547-11/16, is designed for precision tool holding. It features a clamping range that accepts tools with a diameter of up to eleven sixteenths of an inch. This collet is engineered to provide high accuracy and is ideal for high-pressure coolant applications.

• Brand: Techniks
• Clamping Range: 0.6875 inches
• Maximum Coolant PSI: 2000

Product Highlights

This collet is suitable for use with ER, RD, DR, ESX, and BR series standard collet chucks. Its construction from high carbon bearing steel enhances flexibility and tool life.

Product Information

Standard Information

• Brand: Techniks
• Collet Series: ER40

Technical Specifications

• Size: 11/16 inches (17.463 mm)
• Clamping Range: 0.6875 inches (17.46 mm)
• Accuracy TIR: 0.0002
• Max Coolant PSI: 2000
• Body Diameter: 1.61 inches
• Head Diameter: 1.61 inches
• Overall Length: 1.81 inches
• Clamping Hole Length: 1.81 inches
