Techniks 04546-5/16 Tech ER32 5/16 Steel Sealed Collet (No Collapse)

Product Description

The Techniks 04546-5/16 is a high-performance ER32 steel sealed collet designed for precision tooling applications. This collet is suitable for a clamping range of zero point three one two five inches with an accuracy of zero point zero zero zero two. The product is designed to handle high pressure coolant applications up to two thousand PSI while preventing contaminants from entering the tool holder.

• Clamping Range: 0.3125 inches (7.94 mm)
• Accuracy: TIR of 0.0002
• Max Coolant PSI: 2000

Product Highlights

This collet is ideal for use in high coolant pressure environments, providing durability and reliability in machining tasks.

Product Information

Standard Information

• Brand: Techniks
• Collet Series: ER32

Technical Specifications

• Size: 5/16 inches (7.938 mm)
• Clamping Range: 0.3125 inches (7.94 mm)
• Accuracy TIR: 0.0002 inches
• Max Coolant PSI: 2000
• Overall Length: 1.575 inches
• Body Diameter: 1.3 inches
• Head Diameter: 1.3 inches
