Techniks 04544-15/32 ER 20 15/32 Steel Sealed Collet

Product Description

The Techniks ER 20 15/32 Steel Sealed Collet with MPN 04544-15/32 is designed for precision tool holding in high-pressure coolant applications. This collet is suitable for ER series tool holders and features a clamping range perfect for securing various cutting tools.

• Sealed design for maximum coolant pressure up to 2000 psi
• Precision accuracy with TIR of 0.0002 inches
• Manufactured from high carbon steel for durability

Product Highlights

This collet is engineered for high performance in coolant-through applications and ensures reliable tool locking.

Product Information

Standard Information

• Brand: Techniks
• Collet Series: ER20

Technical Specifications

• Size: 15/32 inches
• Clamping Range: 0.4688 inches (11.91 mm)
• Accuracy TIR: 0.0002 inches
• Max Coolant PSI: 2000
• Overall Length: 1.24 inches
• Body Diameter: 0.83 inches
• Head Diameter: 0.83 inches
• Suitable For Use With: ER, RD, DR, ESX, and BR Series Standard Collet Chuck
