Techniks 04543-3/8 TECH ER16 3/8 Steel Sealed Collet (No Collapse)

Product Description

The Techniks 04543-3/8 is a steel sealed collet designed for high-performance applications. This collet fits ER16 series and is ideal for use in environments requiring coolant flow. The design of the collet ensures maximum clamping stability while preventing collapse. It accommodates a clamping range of zero point three seven five inches and can withstand coolant pressures of up to two thousand PSI.

• Compatible with ER, RD, DR, ESX, and BR series standard collet chucks.
• Achieves high precision with accuracy TIR of zero point zero zero zero two inches.
• Made from high carbon bearing steel for increased flexibility and durability.

Product Highlights

This collet features a sealed design that prevents coolant leakage, ensuring the tool holder remains free of contaminants. For enhanced performance, consider using with a PowerCOAT nut.

Product Information

Standard Information

• Brand: Techniks
• Collet Series: ER16

Technical Specifications

• Size: 3/8 inches
• Clamping Range: 0.375 inches (9.530 mm)
• Accuracy TIR: 0.0002 inches
• Max Coolant PSI: 2000
• Body Diameter: 0.67 inches
• Head Diameter: 0.67 inches
• Overall Length: 1.083 inches
• Clamping Hole Length: 1.083 inches
